5.25m x 100m MultiTrack NW18 Nonwoven Geotextile

Specifications

Roll Width: 5.25m
Roll Length: 100m
Area Coverage: 525m²
Tensile Strength:
     -Machine Direction (MD): 18 kN/m
     -Cross Machine Direction (CMD): 18 kN/m
Elongation at Max Load:
     -Machine Direction (MD): 50%
     -Cross Machine Direction (CMD):55%
CBR Puncture Resistance: 3000N
Water Permeability: 70L/m².s
Colour: White
Material: Polypropylene
Weight: 118kg
Compliance & Certifications: CE, ISO 9001:2005

The Geoworks MultiTrack NW18 is a heavy-duty, high-performance nonwoven geotextile specifically engineered for demanding civil engineering, construction, and infrastructure projects.

Manufactured from high-quality polypropylene and needle-punched to create an exceptionally robust and permeable fabric, the MultiTrack NW18 excels in critical applications requiring superior separation, highly effective filtration, and substantial protection. This geotextile provides long-term stability and drainage, safeguarding foundational layers and systems from contamination and degradation under significant loads.

Features & Benefits

• Exceptional Separation: Prevents the intermixing of aggregates with weak or fine sub-grade soils, preserving the structural integrity and load-bearing capacity of heavily trafficked areas.
• Superior Filtration: High permeability combined with fine pore size ensures excellent water flow while effectively preventing the migration of soil fines, protecting drainage systems from clogging and enhancing their lifespan.
• High Puncture Resistance (NW18): Significantly robust needle-punched construction provides outstanding resistance to puncture from sharp aggregates and high installation stresses, ensuring reliability in demanding environments.
• Robust Protection Layer: Ideal for safeguarding critical geomembranes, waterproofing layers, and sensitive underground structures from mechanical damage during installation and ongoing operation.
• Durable Polypropylene Construction: Resistant to chemical and biological degradation, rot, and prolonged UV exposure, guaranteeing long-term performance and durability in challenging ground conditions.
• Optimised Width (5.25m): The extra width compared to standard rolls often reduces the number of overlaps required on larger projects, potentially saving material and installation time.
• Enhanced Load Distribution: Helps to distribute applied loads more evenly over a wider area, reducing stress concentrations and improving overall ground stability.
• Cost-Benefit Ratio: Its robust performance reduces future maintenance costs and enhances the longevity of civil engineering assets, providing excellent long-term value.

The Geoworks MultiTrack NW18 nonwoven geotextile is an indispensable material for significant projects that demand high levels of ground reinforcement, drainage efficiency, and protective layering. It is particularly useful in environments subjected to heavy loads, where soil stability is paramount, or where expensive buried structures need maximum protection.

By providing a durable barrier against soil contamination, ensuring efficient water management, and absorbing localised stresses, it significantly contributes to the structural integrity, longevity, and performance of major infrastructure developments.

Typical Applications

• Major Road & Railway Construction: As a robust separation and filtration layer beneath heavily trafficked areas.
• Waste Containment & Landfills: As a protective layer for geomembranes against puncture from waste materials or sharp sub-grade.
• Large Drainage Systems: High-capacity drainage trenches, attenuation tanks, and culvert wraps where superior filtration and protection are needed.
• Shoreline & River Bank Protection: Beneath rock armour, rip-rap, and scour protection systems to prevent soil erosion and maintain stability.
• Foundations for Heavy Structures: Enhancing the load distribution and stability beneath industrial buildings, bridges, and large-scale foundations.
• Embankments & Dams: Stabilisation and filtration within earth-filled structures to prevent internal erosion.
• Airport Pavements & Aprons: Providing robust separation and drainage for areas subjected to heavy aircraft loads.
• Reservoirs & Ponds: As a protective bedding layer for reservoir and pond liners.

About Geoworks

Geoworks are specialists in comprehensive geosynthetic solutions, offering one of the industry's most extensive ranges, including geotextiles, geogrids, geomembranes, geomats, geocells, and geopaving. They pride themselves on providing a complete, integrated solution for both domestic and commercial clients, simplifying procurement and ensuring product compatibility.

Committed to quality, durability, and sustainable development, their innovative geosynthetics are engineered to enhance soil reinforcement, erosion control, drainage, and protection, delivering reliable, long-lasting, and environmentally responsible solutions for infrastructure and construction projects nationwide.

Please Note: All images shown are used for illustration purposes only and may differ from the actual product supplied.
