PLASSON 90dg Compression Tee

Specifications

Product Type: MDPE Tee
Model Type: 90dg Tee
Nominal Diameter Mains: 20mm - 160mm
Nut Material: Polypropylene, high-grade copolymer
Water Pressure Rating: PN16
Weight: 0.15kg – 14.74kg

This 90 degree PLASSON equal compression tee is designed for use with MDPE water pipe to create a 90 degree branch from the main line. Able to withstand working pressures of up to 16 bar, this WRAS approved product is suitable for use in systems conveying water and other fluids in urban and inter-urban infrastructure, industrial, mining, landscape and farming, as well as optical fibre duct systems.

Please note: PTFE tape is strongly recommended in threaded joints. This fitting is for connecting three pipes of equal diameter. To join pipes of unequal diameter, checkout our range of MDPE Reducing Tees.

Product Features:

• Quality Compression fitting
• Fast and simple to install
• Available in sizes from 50mm to 63mm
• Tested to high standards - ISO 17885 for Water Applications, AS/NZS 4129, ISO 7/1, BS 21, DIN 2999, UNI 9561, NEN 3258, AS 1722, DIN 8076

Product Components:

• 3 O-Rings (20mm – 32mm)
• 3 Split Rings (20mm – 63mm)
• 3 Nuts (20mm – 110mm)
• 3 Seals (50mm – 110mm)
• 3 Inserts (75mm – 110mm)

Available Sizes: (Please ensure to select the correct option before purchase)

• 20mm (20mm x 20mm x 20mm - for creating a 90 degree branch with 20mm MDPE)
• 25mm (25mm x 25mm x 25mm - for creating a 90 degree branch with 25mm MDPE)
• 32mm (32mm x 32mm x 32mm - for creating a 90 degree branch with 32mm MDPE)
• 50mm (50mm x 50mm x 50mm - for creating a 90 degree branch with 50mm MDPE)
• 63mm (63mm x 63mm x 63mm - for creating a 90 degree branch with 63mm MDPE)
• 90mm (90mm x 90mm x 90mm - for creating a 90 degree branch with 90mm MDPE)
• 110mm (110mm x 110mm x 110mm - for creating a 90 degree branch with 110mm MDPE)
• 160mm (160mm x 160mm x 160mm - for creating a 90 degree branch with 160mm MDPE)

Customer Notice - Chemical Resistance: Polyacetal split rings and NBR o-rings, suitable for water, are supplied as standard. CPVC split rings and EPDM or FPM o-rings and seals are available. For aggressive chemical applications, the end user is advised to test suitability.

Customer Notice - Operating Temperatures: While these fittings can withstand the same temperature as polyethylene pipe, they are not intended for use in hot water applications. However, they will withstand sub-zero temperatures.
