MDPE Compression Fittings
PLASSON PE to Male BSP Adaptor.
  • PLASSON PE to Male BSP Adaptor.

PLASSON PE to Male BSP Adaptor

09117020
1-3 working days
3-5 working days
Small Item
From £4.46
£4.46 - £97.62
From £3.72 ex. VAT

Delivery from £15 Within 3 Working Days

Carbon neutral delivery from JDP vehicles

Return within 30 days for a full refund

Product Details

Specifications

Product Type: MDPE Adaptor
Model Type: Male Threaded Adaptor
Nominal Diameter Mains: 20mm - 110mm
Threaded Outlet Diameter: ½” - 4” (Imperial BSP)
Body Material: Polypropylene, high-grade copolymer
Water Pressure Rating: PN16
Weight:
 0.06kg – 1.94kg

This PLASSON male (BSP) threaded adaptor is designed for use with metric MDPE water pipe and any standard imperial male BSP connection. Able to withstand working pressures of up to 16bar, this WRAS approved product is suitable for use in systems conveying water and other fluids in urban and inter-urban infrastructure, industrial, mining, landscape and farming, as well as optical fibre duct systems.

Please note: PTFE tape is strongly recommended in threaded joints.

Product Features:

  • Made from MDPE
  • Quality Compression fitting
  • Tapered male thread
  • Fast and simple to install
  • Available in sizes from 20mm to 63mm
  • Metric x MI BSP
  • Tested to high standards - ISO 17885 for Water Applications, AS/NZS 4129, ISO 7/1, BS 21, DIN 2999, UNI 9561, NEN 3258, AS 1722, DIN 8076

Product Components:

  • 1 Split Ring (Polyacetal)
  • 1 Nut (Polypropylene, high-grade copolymer)
  • 1 Seal (NBR)

Available Sizes: (Please ensure to select the correct option before purchase)

  • 20mm x 1/2" (for connection with 20mm MDPE & standard 1/2" male BSP connection)
  • 20mm x 3/4" (for connection with 20mm MDPE & standard 3/4" male BSP connection)
  • 20mm x 1" (for connection with 20mm MDPE & standard 1" male BSP connection)
  • 25mm x 1/2" (for connection with 25mm MDPE & standard 1/2" male BSP connection)
  • 25mm x 3/4" (for connection with 25mm MDPE & standard 3/4" male BSP connection)
  • 25mm x 1" (for connection with 25mm MDPE & standard 1" male BSP connection)
  • 32mm x 3/4" (for connection with 32mm MDPE & standard 3/4" male BSP connection)
  • 32mm x 1" (for connection with 32mm MDPE & standard 1" male BSP connection)
  • 32mm x 1 1/4" (for connection with 32mm MDPE & standard 1 1/4" male BSP connection)
  • 32mm x 1 1/2" (for connection with 32mm MDPE & standard 1 1/2" male BSP connection)
  • 50mm x 1" (for connection with 50mm MDPE & standard 1" male BSP connection)
  • 50mm x 1 1/4" (for connection with 50mm MDPE & standard 1 1/4" male BSP connection)
  • 50mm x 1 1/2" (for connection with 50mm MDPE & standard 1 1/2" male BSP connection)
  • 50mm x 2" (for connection with 50mm MDPE & standard 2" male BSP connection)
  • 63mm x 1 1/4" (for connection with 63mm MDPE & standard 1 1/4" male BSP connection)
  • 63mm x 1 1/2" (for connection with 63mm MDPE & standard 1 1/2" male BSP connection)
  • 63mm x 2" (for connection with 63mm MDPE & standard 2" male BSP connection)
  • 63mm x 2 1/2" (for connection with 63mm MDPE & standard 2 1/2" male BSP connection)
  • 90mm x 2" (for connection with 90mm MDPE & standard 2" male BSP connection)
  • 90mm x 2 1/2" (for connection with 90mm MDPE & standard 2 1/2" male BSP connection)
  • 90mm x 3" (for connection with 90mm MDPE & standard 3" male BSP connection)
  • 90mm x 4" (for connection with 90mm MDPE & standard 4" male BSP connection)
  • 110mm x 2" (for connection with 110mm MDPE & standard 2" male BSP connection)
  • 110mm x 3" (for connection with 110mm MDPE & standard 3" male BSP connection)
  • 110mm x 4" (for connection with 110mm MDPE & standard 4" male BSP connection)

Customer Notice - Chemical Resistance: Polyacetal split rings and NBR o-rings, suitable for water, are supplied as standard. CPVC split rings and EPDM or FPM o-rings and seals are available. For aggressive chemical applications, the end user is advised to test suitability.

Customer Notice - Operating Temperatures: While these fittings can withstand the same temperature as polyethylene pipe, they are not intended for use in hot water applications. However, they will withstand sub-zero temperatures.

SKU:
09117020
Availability:
Within 3 Working Days
Product Type:
Compression
Install Type:
Adaptor
Brand:
Plasson
Courier:
Y
